Liam Pipes and Tubes, based in Houston, USA, provides Titanium EFW (Electric Fusion Welded) Pipe—a cost-effective option for larger-diameter titanium pipes. Through electric resistance or high-frequency welding, we shape pipes from titanium plate or coil (Grades 2, 7, or 12) with precise control. Weld seams are minimally deformed and weld integrity is verified by ultrasonic and radiographic testing. Post-weld heat treatment and pickling improve performance and corrosion resistance. Conforming to ASTM B861/B862 specifications, our EFW pipe is delivered in standard and special sizes to petrochemical, industrial, and offshore customers looking for cost-saving large diameter solutions with guaranteed quality.
Titanium EFW Pipe is made from commercially pure titanium (Grades 1–2) or alloyed grades (7, 12) through electric fusion welding. Tensile strength is generally between 240 MPa to 550 MPa; yield strength from 170 MPa to 450 MPa. Elongation rates are 15–30%. Low density (~4.5 g/cm³) and a natural oxide layer ensure corrosion resistance. Weld seams are carefully controlled to reduce heat-affected zones and are ultrasonically/radiographically inspected. Pipes are usually annealed and stress-relieved after welding to recapture mechanical properties, with a guarantee for dimensional accuracy, toughness, and fatigue resistance even in the weld area.
Specifications : ASTM B337 / ASME SB337
Dimensions : ASTM, ASME and API
Size : 8″ NB to 24″ NB
Wall Thickness : 0.5 to 150mm Thick
Schedules : SCH 5S, 10S,10, 20, 40S, 40, STD, 60, 80S, 80, XS, 100, 120, 140, 160 & XXS
Length : Single Random, Double Random & Required Length
Form : Round, Square, Rectangular, Hydraulic Pipes
End : Plain end, Bevelled end
Type : Electric Resistance Welded
| Grade | Ti | C | Fe | H | N | O | Al | V |
| Titanium Gr 2 | 99.2 min | 0.1 max | 0.3 max | 0.015 max | 0.03 max | 0.25 max | – | – |
| Titanium Gr 5 | 90 min | – | 0.25 max | – | – | 0.2 max | 6 min | 4 min |
| Grade | Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| Ti Gr 2 | 4.5 g/cm3 | 1665 °C (3030 °F) | Psi – 49900 , MPa – 344 | Psi – 39900 , MPa – 275 | 20 % |
| Ti Gr 5 | 4.43 g/cm3 | 1632 °C (2970 °F) | Psi – 138000 , MPa – 950 | Psi – 128000 , MPa – 880 | 14 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Titanium EFW Pipes from Liam Pipes and Tubes ensures exceptional quality, durability, and performance for demanding industrial applications. Our alloy steel pipes are manufactured using high-grade materials that offer superior resistance to corrosion, high pressure, and extreme temperatures. We adhere to stringent quality control standards to guarantee reliable performance in critical sectors such as oil and gas, power generation, and construction. With a commitment to customer satisfaction, Liam Pipes and Tubes provides tailored solutions, timely delivery, and expert support, making us a trusted partner for all your alloy steel pipe needs.
Liam Pipes and Tubes, one of the largest suppliers of Titanium EFW Pipes in Houston , USA, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Titanium EFW Pipes to meet your specific requirements. Our team at Liam Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@liampipes.us.
Titanium EFW Pipes are best suited for large-diameter cost-conscious systems. Chemical and petrochemical processes install them in chemical transfer systems, storage headers, and process lines. Seawater lines, ballast systems, and chemical injection networks use them on offshore platforms. Power plants and desalination facilities utilize them for brine, cooling water circuits, and condenser circuits. Industrial manufacturing utilizes them in distribution headers, large manifolds, and tanks. They are also applied in pulp & paper, food & beverage, and pharmaceutical systems handling corrosive fluids. With weld quality certification and large diameter capabilities, titanium EFW piping delivers performance, value, and longevity.
