Titanium Pipes Manufacturer, Supplier and Exporter in Houston , USA

Liam Pipes and Tubes Houston produces high–quality Titanium Pipes, welded and seamless for different industrial purposes. We use high-class titanium alloys (Grades 1–5) to provide superior corrosion resistance along with mechanical properties. We have in–house capabilities of precision welding, heat treatment, and post-weld examination, following ASTM B338/B337 standards. We accommodate custom measurements, wall thickness, and surface finishes to fit client project specifications. These pipes are used by power generation, desalination, petrochemical, and chemical processing industries where they must be reliable and capable of withstanding tough environments. Logistics from Houston provide on-time delivery and local assistance.

ASTM B861 Grade 2 Pipe Price In USA, Gr 5 Titanium Pipe supplier in United kingdom, Titanium pipe Manufacturers In Houston , ASTM B861 Pipe In Los Angeles , Titanium Grade 5 Pipe In Houston, Titanium Round Pipe In Texas, Titanium Pipes Manufacturer In California.

Our Titanium Pipes utilize commercially pure titanium (Grades 1–4) and alloyed titanium (Grade 5, Ti‑6Al‑4V). Their tensile strength is between 240 MPa and 950 MPa, and yield strength between 170 MPa and 830 MPa. Elongation varies between 10–30%, alloy-dependent. Low density of ~4.5 g/cm³ provides excellent strength-to-weight ratio. All grades have good corrosion resistance in chloride-rich, acidic, and marine atmospheres. Welded pipes are tested non-destructive, with seamless versions being grain-aligned for enhanced impact resistance. Heat treatment and pickling are used to provide best mechanical properties and surface integrity, as per ANSI/ASME specifications.

Titanium Pipes Specification

Titanium Pipe International Specification	ASTM B337 ASME SB337 / ASTM B861 ASME SB861 NACE MRO 175-94, VdTÜV 230/2
Dimensional tolerances	DIN 17861 D3/T3 or closer
Standard Specification	ASME, ASTM, AISI, AMS, JIS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB
Titanium Seamless Pipe Size	OD: 4 to 219mm Wall Thickness: 0.5 to 20mm
Grade 2 Titanium Welded Pipe Size	OD: 5.0 – 1219.2 mm
Titanium Grade 5 EFW Pipe Size	OD: 5.0 – 1219.2 mm
Titanium Grade 2 Pipe WT	SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS
Grade 5 Titanium Pipe manufacturing techniques	Seamless / ERW / EFW/ Welded / Fabricated / CDW/ LSAW/ Seam-Welded / Redrawn
Origin of ASTM B861 Titanium Alloy pipe material	Indian, European, Korean, Japanese
Titanium Metal Gr 5 Pipe End Types	BE : Beveled end BBE : Bevel both ends BLE : Bevel large end BSE : Bevel small end TOE / POE = Treaded One End / Plain One End TOE / BOE = Treaded One End / Beveled One End POE / BOE = Plain One End / Beveled One End TBE = Treaded Both Ends PBE = Plain Both Ends
Form	Round, Square, Rectangular
Ti Metal Gr 2 Pipe Length	Single Random, Double Random & Required Length End: Plain End, Beveled End, Treaded
Titanium Cp Grade 5 Pipe Delivery Condition	Annealed and Pickled, Hot Finished, Polished, Bright Annealed, Cold Drawn
Ti-6AL-4V ELI Titanium Pipe Packing	Ply Wooden Boxes PE Fabric Bundles Steel Strips Bundled Standard seaworthy export packing Plastic Bags, or as required
CP Titanium Pipe Value Added Services	Cut to size, thread, and groove
Port	Mumbai, India
Stocking distributor of leading Titanium Pipe manufacturers	Nippon Steel Corporation, Japan make Titanium Grade 5 Pipe Sumitomo Metals, Japan make Ti Alloy Cp Grade 2 Pipes Sanyo Special Steel, Japan make Titanium Pipe Schoeller Bleckmann, Austria make Grade 2 Titanium Seamless Pipe Seah Steel Corporation, Korea make Titanium Grade 2 Seamless Pipe Kobe Special Tube, Japan make Grade 5 Titanium Pipe Tubacex Tubos Inoxidables S.A., Spain make ASTM B861 Titanium Alloy Pipe
CP Titanium Pipe Dimensional Specification	ANSI/ ASME B36.10, B36.19, B2.1
Marking on Ti-6al-4v Titanium Pipe	Specification Material Grade Nominal Size Schedule or Wall Thickness Method of Manufacturing (Seamless or Welded) Heat Number Manufacturer / supplier Name or Custom Logo – on request Marked Pipe Sample: SEAMLESS TITANIUM PIPE ASTM B861 GR2 SCH 40S OD 48 X WT 0.6MM HEAT NO. XXXX Do not forget to compare our price with other Titanium pipe manufacturers in India

Titanium Pipes Chemical Composition

Titanium Gr 2	C	Ti	N	Fe	H	O	V	Al
Titanium Gr 2	0.1 max	99.2 min	0.03 max	0.3 max	0.015 max	0.25 max	–	–

Titanium Gr 5	C	Ti	N	Fe	H	O	V	Al
Titanium Gr 5	0.10 max	90 min	0.05 max	0.40 max	0.015 max	0.20 max	3.5-4.5	5.5-6.75 max

Titanium Pipes Mechanical Properties

Titanium Alloy	UNS	Proof strength Rp0.2 MPa min	Tensile Stress Rm MPa min	Elongation A % min
Cp Ti Grade 1	R50250	138-310	240	24
Cp Ti Grade 2	R50400	275-450	345	20
Cp Ti Grade 3	R50550	380-550	450	18
Ti Grade 7	R52400	275-450	345	20
Ti Grade 9	R56320	483	620	15
Ti Grade 11	R52250	138-310	240	24
Ti Grade 12	R53400	345	483	18
Ti Grade 16	R52402	275-450	345	20
Ti Grade 17	R52252	138-310	240	24
Ti Grade 26	R52404	275-450	345	20
Ti Grade 28	R52254	483	620	15

If You Are Looking To Buy High Quality

We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.

Manufacturer of ASTM B862 Gr 2 Pipe in USA, Buy Titanium exhaust pipe in custom length and wall thickness In United kingdom, ASTM B861 Titanium Pipe In Houston , Titanium Grade 2 Pipe In Los Angeles , Ti-6AL-4V ELI Pipes In Houston, Ti-6al-4v Titanium Pipe In Texas, Ti Alloy Cp Grade 2 Pipe In California.

Why Choose Titanium Pipes from Liam Pipes and Tubes?

Choosing Titanium Pipes from Liam Pipes and Tubes ensures exceptional quality, durability, and performance for demanding industrial applications. Our alloy steel pipes are manufactured using high-grade materials that offer superior resistance to corrosion, high pressure, and extreme temperatures. We adhere to stringent quality control standards to guarantee reliable performance in critical sectors such as oil and gas, power generation, and construction. With a commitment to customer satisfaction, Liam Pipes and Tubes provides tailored solutions, timely delivery, and expert support, making us a trusted partner for all your alloy steel pipe needs.

Customer Support

On Time Deliveries

Largest Inventory

Worldwide Shipping

Largest Titanium Pipes Supplier in Houston , USA

Liam Pipes and Tubes, one of the largest suppliers of Titanium Pipes in Houston , USA, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.

ASTM B861 Grade 2 Pipe Price In USA, Gr 5 Titanium Pipe supplier in United kingdom, Titanium pipe Manufacturers In Houston , ASTM B861 Pipe In Los Angeles , Titanium Grade 5 Pipe In Houston, Titanium Round Pipe In Texas, Titanium Pipes Manufacturer In California.

Types of Titanium Pipes

Are Custom Sizes Available for Titanium Pipes?

Yes, we offer custom sizes for Titanium Pipes to meet your specific requirements. Our team at Liam Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@liampipes.us.

Manufacturer of ASTM B862 Gr 2 Pipe in USA, Buy Titanium exhaust pipe in custom length and wall thickness In United kingdom, ASTM B861 Titanium Pipe In Houston , Titanium Grade 2 Pipe In Los Angeles , Ti-6AL-4V ELI Pipes In Houston, Ti-6al-4v Titanium Pipe In Texas, Ti Alloy Cp Grade 2 Pipe In California.

Titanium Pipes are applied in industries with hostile media or harsh conditions. They’re applied for corrosive fluid processing and handling acids in chemical and petrochemical factories. Seawater desalination and power generation cooling systems employ them in condenser and heat-exchanger piping. Offshore oil and gas platforms employ titanium corrosion-resistant piping in firewater, seawater lift, and chemical injection lines. They serve geothermal systems, pulp and paper mills, and food processing. Industrial production systems take advantage of titanium‘s strength and sanitation. Wherever high pressure, acidity, or marine conditions are present, our titanium piping provides long service life and compliance.
