Home > Stainless Steel > Stainless Steel Heat Exchanger Tubing
Liam Pipes & Tubes, a Houston-based, USA-based company is a world-class manufacturer of stainless steel heat exchanger tubes renowned for their superior quality and performance. With a leadership focus on precision and innovation, we provide precision-engineered tubing solutions tailored to address the thermal as well as corrosion issues in a diverse range of industries. Our stainless steel products are engineered from top-grade stainless steel materials, providing durability, efficient heat transfer, and high resistance to extreme temperatures and corrosive environments. Liam prioritizes customer satisfaction—reliable service, technical know-how, and bespoke solutions that respond to the unique requirements of each industry and application.
The stainless steel heat exchanger tubes consist mainly of iron, 10–30% chromium, and nickel, with optional molybdenum for added corrosion protection. This alloy composition offers high mechanical properties, such as tensile strength up to 750 MPa and yield strength of 205–310 MPa. These tubes are designed to perform for extended periods under high-pressure and high-temperature conditions. They have a smooth bore surface that enhances excellent heat transfer and minimizes fouling and scaling. Widely recognized for their corrosion, thermal, and oxidation resistance, these tubes are best suited for application in chemically aggressive conditions and processes where reliability and life are paramount.
| Marking | All Stainless Steel Heat Exchanger tubes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
|---|---|
| Stainless Steel Heat Exchanger Tube Size | 3.35 mm OD To 101.6 mm OD |
| Swg & Bwg | 10 Swg., 12 Swg., 14 Swg., 16 Swg., 18 Swg., 20 Swg. |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| SS tube Length | Single Random, Double Random, Standard & Cut length |
| Stainless Steel Heat Exchanger Tube Type | Seamless, ERW, EFW, Welded, Fabricated |
| Stainless Steel Heat Exchanger Tube Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF |
| Stainless Steel tube Form | Round, Coil, Square, Rectangular, Boiler, Hydraulic, Straight or ‘U’ bent Tubes, Hollow, LSAW Tubes Etc. |
| Stainless Steel Welded Tube Size | 6.35 mm OD To 152 mm OD |
| End | Plain End, Beveled End, Treaded |
| Specialize in | Stainless Steel Capillary Tube & Other Odd Size Stainless Steel Heat Exchanger & Condenser Tubes |
| Application | Oil Tube, Gas Tube, Fluid Tube, Boiler and Heatexchanger |
| Stainless Steel Tube Standards | ASTM B/ASME SB674 / SB677 |
| Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Stainless Steel Heat Exchanger tubing wall thickness | 0.020″ –0.220″, (special wall thicknesses available) |
| Material | C | Mn | Si | P | S | Cr | MO | Ni | Cu | |
| SS | min. | – | – | – | – | – | 19.0 | 4.0-5.0 | 23.0 | 1.0 |
| max. | 0.20 | 2.0 | 1.0 | 0.045 | 0.035 | 23.0 | 28.0 | 2.0 | ||
| Material | Tensile Strength (MPa) min | Yield Strength 0.2% Proof (MPa) min | Elongation (% in 50mm) min | Hardness | |
| Rockwell B (HR B) max | Brinell (HB) max | ||||
| SS | 490 | 220 | 35 | 70-90 typical | – |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Stainless Steel Heat Exchanger Tubing from Liam Pipes and Tubes ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in stainless steel products ensures you receive a top-tier solution tailored to your needs.
Liam Pipes and Tubes, one of the largest suppliers of Stainless Steel Heat Exchanger Tubing in Houston , USA, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Stainless Steel Heat Exchanger Tubing to meet your specific requirements. Our team at Liam Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@liampipes.us.
Stainless steel heat exchanger tubing finds broad usage in industries where there is a need for effective heat transfer and corrosion resistance. In the chemical processing industry, it allows safe and efficient heat exchange between fluids. The oil and gas industry employs it in petrochemical facilities and refineries for cooling and heating processes. It is a key part in HVAC systems, providing efficient climate control. Its cleanliness makes it an essential choice in the manufacturing of food products and pharmaceuticals. It also provides thermal regulation in power plants, with cleanliness, performance, and durability in demanding operating conditions.
