Houston, USA-based Liam Pipes & Tubes produces and provides high-quality Nickel Alloy Welded Pipes for high-performance industrial processes. The pipes are produced by welding nickel alloy strips or plates to provide high corrosion resistance, high-temperature strength, and durability for a long period of time. Round and available in Inconel 600, Inconel 625, Monel 400, and Hastelloy C276 grades, the welded pipes meet the specifications of ASTM B517, B619, as well as other international standards. Equipped to work in aggressive conditions, these pipes are commonly utilized in chemical process environments, marine systems, heat exchangers, and power plants. Each pipe is weld integrity tested and measured accurately to ensure repeat performance and quality.
Nickel Alloy Welded Pipes have 60–72% nickel content, with varying amounts of chromium (up to 23%), molybdenum, copper, and iron based on grade. Tensile strength varies between 500–950 MPa, yield strength 200–400 MPa, and elongation 30–40%. The alloys are highly resistant to oxidation, acids, alkalis, and seawater. Non-destructive examination by X-ray or ultrasonic testing is carried out on the welded pipes for weld reliability. Their mechanical and corrosion-resisting properties are not affected even when the temperatures are higher, so they are perfect for pressure-resistant applications and lengthy service life.
| ASTM Specification | Astm B829 ASME SB829 |
|---|---|
| Standard | ASTM, ASME, JIS, AISI, AMS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB |
| ASTM B829 Nickel Alloy Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| ASTM B725 Nickel Alloy Welded Pipe Size | 5.0 – 1219.2 mm |
| Nickel-Cobalt Alloys EFW Pipe size | 5.0 – 1219.2 mm |
| Swg & Bwg | 12 Swg., 10 Swg., 16 Swg., 14 Swg., 20 Swg., 18 Swg., |
| Nickel Pipe Schedule | XS, SCH30, SCH40, XXS, SCH80, SCH120, SCH60, SCH140, STD, SCH10, SCH10S, SCH40S, SCH80, SCH20, SCH5, SCH160 |
| Nickel pipe Length | Double Random, Single Random, Standard & Cut length Pipe |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish, etc |
| Form | Nickel are available in form of Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc. |
| Type of Nickel Alloy Pipe | Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Nickel |
| Nickel pipe End | Plain End, Beveled End, Treaded Pipe, Screwed ends |
| Marking on Nickel Steel Pipe | All Astm B725 Nickel Alloy Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application of Nickel pipe | Dairy Pipe, Oil Pipe, Gas Pipe, Fluid Pipe, Boiler Pipe for Chemical Industry |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialize in | Large Diameter NickelPipe |
| Nickel pipe manufacturing Technique | Cold drawn, hot drawn, bright annealed, solid solution, hot extruding |
| Nickel pipe Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Heat Treatment Charts, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Nickel HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP) |
| Nickel 200 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| 99.0 Min | 0.15 Max | – | 0.35 Max | 0.1 Max | 0.4 Max | – | 0.01 Max | 0.25 Max | – | |
| Nickel 201 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Balance | 0.15 Max | – | 0.35 Max | 0.35 Max | 0.40 Max | – | 0.01 Max | 0.25 Max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Nickel Alloy Welded Pipes from Liam Pipes and Tubes ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in nickel alloy products ensures you receive a top-tier solution tailored to your needs.
Liam Pipes and Tubes, one of the largest suppliers of Nickel Alloy Welded Pipes in Houston , USA, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for nickel alloy products in the region.
Yes, we offer custom sizes for Nickel Alloy Welded Pipes to meet your specific requirements. Our team at Liam Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@liampipes.us.
Nickel Alloy Welded Pipes have a wide range of applications in chemical plants, power plants, offshore oil rigs, and shipbuilding systems. They carry corrosive fluids, acids, and gases in chemical process lines and heat exchangers. In nuclear and aerospace applications, they are being used in exhaust systems, reactors, and high-temperature pipes. The pipes are also being used in desalination plants, pharma processing, and food-grade systems, where corrosion resistance and cleanliness are required. With better weldability and mechanical properties, Nickel Alloy Welded Pipes are relied upon for long-term performance in a few of the world‘s toughest and most demanding conditions.
