Home > Nickel Alloy > Nickel Alloy Seamless Pipes
Liam Pipes & Tubes provides high-performance Nickel Alloy Seamless Pipes from Houston, USA, designed for exceptional performance in sour chemical and high-temperature conditions. Weld-free, these pipes provide uniform strength and leak-tight construction. Available in grades like Inconel® 600, Inconel® 625, Hastelloy® C276, and Monel® 400, these are in accordance with ASTM B161, B167, and B622 standards. Seamless construction provides superior pressure resistance and structure strength. Suitable for use in petrochemical, power generation, marine, and aerospace applications, our nickel alloy seamless pipes provide superior corrosion resistance, thermal stability, and mechanical strength in harsh operating conditions.
Nickel Alloy Seamless Pipes contain 60–72% nickel, with various elements such as chromium (Cr), molybdenum (Mo), iron (Fe), and copper (Cu) depending on the grade. Tensile strength is usually 550–950 MPa, yield strength is 200–450 MPa, and elongation is usually between 30–45%. These pipes are mechanically sound even at elevated temperatures and in corrosive environments. Cold- or hot-finished types exist, usually annealed for enhanced ductility. Seamless construction provides pressure uniformity and absence of weak spots, and they find application where reliability and resistance to leaks are paramount.
| ASTM Specification | Astm B829 ASME SB829 |
|---|---|
| Standard | ASTM, ASME, JIS, AISI, AMS, EN, SAE, DIN, NF, TOCT, DS, DTD, GB |
| ASTM B829 Nickel Alloy Seamless Pipe Size | 4 to 219mm W. T.: 0.5 to 20mm |
| ASTM B725 Nickel Alloy Welded Pipe Size | 5.0 – 1219.2 mm |
| Nickel-Cobalt Alloys EFW Pipe size | 5.0 – 1219.2 mm |
| Swg & Bwg | 12 Swg., 10 Swg., 16 Swg., 14 Swg., 20 Swg., 18 Swg., |
| Nickel Pipe Schedule | XS, SCH30, SCH40, XXS, SCH80, SCH120, SCH60, SCH140, STD, SCH10, SCH10S, SCH40S, SCH80, SCH20, SCH5, SCH160 |
| Nickel pipe Length | Double Random, Single Random, Standard & Cut length Pipe |
| Finish | Polished, AP (Annealed & Pickled), BA (Bright & Annealed), MF, NO.1, NO.4, 2B, BA, HL, 8K, Mirror finish, etc |
| Form | Nickel are available in form of Round, Square, Hollow, Rectangular, Hydraulic, Coiled, Straight Pipes, “U” Shape, Pan Cake Coils etc. |
| Type of Nickel Alloy Pipe | Seamless / ERW/ EFW / Welded / Fabricated / CDW / DOM / CEW Nickel |
| Nickel pipe End | Plain End, Beveled End, Treaded Pipe, Screwed ends |
| Marking on Nickel Steel Pipe | All Astm B725 Nickel Alloy Pipes are marked as follows: Standard, Grade, OD, Thickness, Length, Heat No. (Or according to the customer’s request.) |
| Application of Nickel pipe | Dairy Pipe, Oil Pipe, Gas Pipe, Fluid Pipe, Boiler Pipe for Chemical Industry |
| Value Added Service | Draw & Expansion as per required Size & Length, Polish (Electro & Commercial) Annealed & Pickled Bending, Machining Etc. |
| Specialize in | Large Diameter NickelPipe |
| Nickel pipe manufacturing Technique | Cold drawn, hot drawn, bright annealed, solid solution, hot extruding |
| Nickel pipe Test Certificate | Manufacturer Test Certificate Laboratory Test Certificate from Govt. Approved Lab. Under Third Party Inspection |
| Material Test Certificates (MTC) | Material Test Certificates (MTC) as per EN 10204/3.1B, EN 10204 3.1 and EN 10204 3.2, 100% Radiography Test Report, Heat Treatment Charts, Raw Materials Certificate, Third Party Inspection Report, Fumigation Certificates, Nickel HS Code Commercial Invoice, Form A for Generalized System of Preferences (GSP) |
| Nickel 200 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| 99.0 Min | 0.15 Max | – | 0.35 Max | 0.1 Max | 0.4 Max | – | 0.01 Max | 0.25 Max | – | |
| Nickel 201 | Ni | C | Mo | Mn | Si | Fe | P | S | Cu | Cr |
| Balance | 0.15 Max | – | 0.35 Max | 0.35 Max | 0.40 Max | – | 0.01 Max | 0.25 Max | – |
| Density | Melting Point | Yield Strength (0.2%Offset) | Tensile Strength | Elongation |
| 8.9 G/Cm3 | 1446 °C (2635 °F) | Psi – 21500 , MPa – 148 | Psi – 67000 , MPa – 462 | 45 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Nickel Alloy Seamless Pipes from Liam Pipes and Tubes ensures high quality and durability, as these pipes offer excellent corrosion resistance and strength. Our commitment to exceptional service and reliable delivery guarantees customer satisfaction across various industrial applications. Our expertise in nickel alloy products ensures you receive a top-tier solution tailored to your needs.
Liam Pipes and Tubes, one of the largest suppliers of Nickel Alloy Seamless Pipes in Houston , USA, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for nickel alloy products in the region.
Yes, we offer custom sizes for Nickel Alloy Seamless Pipes to meet your specific requirements. Our team at Liam Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@liampipes.us.
Nickel Alloy Seamless Pipes are particularly suitable for chemical processing, nuclear reactors, heat exchangers, and aerospace fluid systems. In the oil & gas industry, they‘re utilized for sour gas and offshore. They find vital applications in desalination plants, pharmaceutical processing, and marine engineering, where seawater and corrosive chemicals attack regular piping. In power generation, they‘re employed in superheaters and steam lines at high temperatures. The smooth finish guarantees safe operation under high-pressure and high-vibration environments, thereby meeting the requirements of mission-critical applications that require long life and resistance to corrosion, stress, and extreme temperature.
