Home > Incoloy > Incoloy Coil Tubing
Liam Pipes and Tubes, located in Houston, USA, stands out as a top manufacturer and supplier of Incoloy coil tubing, delivering high-performance solutions for a variety of industrial needs. Renowned for their precision-engineered products and unwavering commitment to quality, the company specializes in seamless Incoloy coil tubing that’s built to perform reliably even in the harshest environments. Thanks to their advanced manufacturing capabilities and strict adherence to global standards, Liam Pipes and Tubes offers tubing that boasts exceptional corrosion resistance, flexibility, and a long service life. Their coil tubing is perfect for continuous lengths, which cuts down on the need for fittings and ensures efficient, leak-free installations in critical systems.
Typically, Incoloy coil tubing is crafted from nickel-iron-chromium alloys like Incoloy 825 and Incoloy 800, often enhanced with molybdenum, copper, and titanium to boost resistance against corrosion and high temperatures. These alloys provide impressive mechanical properties, including tensile strength ranging from 550 to 650 MPa and yield strength between 220 and 300 MPa, along with elongation rates of about 30%. The coil design allows for long, continuous lengths without joints, which helps minimize potential leak points. The material maintains its structural integrity under pressure and thermal cycling, while also offering excellent resistance to pitting, crevice corrosion, and stress-corrosion cracking.
| Thickness | 0.3mm – 50 mm, SCH 5, SCH10, SCH 40, SCH 80, SCH 80S, SCH 160, SCH XXS, SCH XS |
| Outer Diameter | 6.00 mm OD up to 914.4 mm OD, Sizes up to 24” NB |
| Type | Seamless / ERW / Welded / Fabricated / CDW |
| Form | Round Tubes, Square Tubes, Rectangular Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tubes |
| Length | Single Random, Double Random & Required Length |
| End | Plain End, Beveled End, Treaded. |
Properties | Metric | Imperial |
Density | 8.14 g/cm³ | 0.294 lb/in³ |
Melting point | 1385°C | 2525°F |
|
Element |
Content (%) |
|
Nickel, Ni |
38-46 |
|
Iron, Fe |
22 |
|
Chromium, Cr |
19.5-23.5 |
|
Molybdenum, Mo |
2.50-3.50 |
|
Copper, Cu |
1.50-3.0 |
|
Manganese, Mn |
1 |
|
Titanium, Ti |
0.60-1.20 |
|
Silicon, Si |
0.50 |
|
Aluminum, Al |
0.20 |
|
Carbon, C |
0.050 |
|
Sulfur, S |
0.030 |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Incoloy coil tubing finds extensive use in oil and gas well intervention, chemical injection, and subsea control systems, thanks to its high strength and outstanding corrosion resistance. It’s particularly well-suited for offshore platforms, downhole operations, and hydraulic or pneumatic control lines in aggressive environments. In the chemical and power sectors, it’s utilized for heat exchanger tubing, instrumentation lines, and fluid delivery systems where long runs and tight bends are essential.
Liam Pipes and Tubes, one of the largest suppliers of Incoloy Coil Tubing in the Houston s, USA. Offers a wide range of high-quality pipes and tubes designed for various industrial applications. Their extensive inventory and dedication to exceptional service make them a trusted choice for Incoloy products in the region, delivering reliable solutions to meet diverse project requirements.
|
Properties |
Metric |
Imperial |
|
Tensile strength (annealed) |
690 MPa |
100000 psi |
|
Yield strength (annealed) |
310 MPa |
45000 psi |
|
Elongation at break (annealed prior to test) |
45% |
45% |
|
Properties |
Metric |
Imperial |
|
|
Thermal expansion co-efficient (at 20-100°C/68-212°F) |
14 µm/m°C |
7.78 µin/in°F |
|
|
Thermal conductivity |
11.1 W/mK |
77 BTU in/hr.ft².°F |
|
Yes, we provide custom sizes for Incoloy Coil Tubes to meet your specific requirements. At Liam Pipes and Tubes, our team is dedicated to delivering tailored solutions for all your piping and tubing needs. For more information, please contact us at sales@liampipes.us.
Incoloy Coil Tubing is widely used in applications that require reliable performance under extreme conditions. Commonly used for well applications, production and injection applications in oil and gas sector. Due to its corrosion resistance and good resistance to high temperature Incoloy coil tubing is ideal for water transfer in high pressure applications in chemical processing, in order to ensure safety -Efficiency is also ensured that. In addition applications in electricity generation can be found for heat exchangers and super heaters. Its flexibility and robustness make it suitable for systems enabling versatility in challenging industrial environments.
