Liam Pipes and Tubes, Houston, USA, is a respected aluminum coil tubing manufacturer and supplier of premium quality Aluminium Coil Tubing that caters to the high-performance requirements of various industries. With years of metal fabrication experience, we deliver products with longevity, flexibility, and superior corrosion resistance. Our aluminium coil tubing is produced to international quality standards, thus being perfect for applications in HVAC, refrigeration, and industrial fluid systems. Supported by cutting-edge technology and customer-centricity, Liam Pipes and Tubes provides tailored, dependable solutions that provide long-term performance and operational effectiveness across a wide range of applications.
Aluminium Coil Tubing is generally made of 99% pure aluminium, reinforced with trace elements of silicon, iron, copper, and magnesium for added strength and durability. It has excellent corrosion resistance, with a tensile strength of 70–150 MPa, depending on the alloy and temper. Having a low weight density of 2.7 g/cm³, it is still light but extremely strong, and thus offers better heat and electrical conductance. Flexibility, simplicity in fabrication, and chemical and rust resistance are its biggest benefits, thereby being perfect for HVAC, refrigeration, medical, and other precision-related uses
Standards : ASTM B345, B241, B429 / ASME SB345, SB241, SB429
Standard : AMS QQ-A-200/8, AMS QQ-A-200/9, AMS 4160/4161/4172
Size : 8 (1-1/2″ / 1.900″)
Outer Diameter : 1″ through 16″
Length : Double Random, Single Random, Cut Length
Thickness : SCH20, SCH30, SCH40, STD, SCH80, XS, SCH60, SCH80, SCH120, SCH140, SCH160, XXS
End : Plain End, Beveled End, Threaded
ASTM B429 / ASME SB429 – Standard Specification for Aluminum-Alloy Extruded Structural Tube and Tube
EN AW-AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Round Tube
ISO AlMg1SiCu – Standard Specification for Aluminum and Aluminum-Alloy Cold / Hot Rolled Tubing
| Alloy | Fe | Si | Mg | Mn | Cu | Zn | Ti | Cr | Others | AI |
| 1100 (min) | 0.35 | 0.25 | 0.01 | 0.01 | 0.05 | 0.01 | 0.020 | Trace | 0.05 (each) | 99.60% |
| 1100 (max) | 0.50 | 0.35 | 0.03 | 0.05 | 0.20 | 0.05 | 0.030 | Trace | 0.15 (total) | remainder |
| 5083 | 0.40 max | 0.40 max | 4.0 / 4.90 | 0.40 / 1.0 | 0.10 max | 0.25 max | 0.15 max | 0.05 / 0.25 | 0.05 max | Bal |
| 6061 | 0.7 | 0.4-0.8 | 0.8-1.2 | 0.15 | 0.15-0.4 | 0.25 | 0.15 | 0.15-0.35 | 0.005/0.15 | Remainder |
| 6068 | 0.50 max | 0.7 – 1.3 | 0.06-1.20 | 0.40-1.00 | 0.10 max | 0.20 max | 0.10 max | 0.25 max | 0.05 max | Bal |
| 7075 min | 2.10 | 1.20 | 5.10 | 0.18 | ||||||
| 7075 max | 0.50 | 0.40 | 2.90 | 0.30 | 2.00 | 6.10 | 0.20 | 0.28 | 0.05 |
| Alloy | Temper | UTS(Mpa) | % Elongation | Tensile Strength | Hardness Brinell | Proof Stress | Yield Strength (PSI) | Shear Strength (PSI) | Brinell Hardness | |||
| Min | Max | 0.5 mm -0.8 mm | 0.81 mm – 1.30 mm | 1.30 mm – above | ||||||||
| 1100 | O | 75 | 110 | 20 | 25 | 29 | ||||||
| H12 | 95 | 130 | 5 | 6 | 7 | |||||||
| H14 | 110 | 145 | 3 | 4 | 5 | |||||||
| H16 | 130 | 165 | 2 | 3 | 4 | |||||||
| H18 | 150 | — | 2 | 2 | 3 | |||||||
| 5083 | 12 Min % | 275 – 350 MPa | 75 HB | 125 Min MPa | ||||||||
| 6061 | – | 45,000 | 12 | 40,000 | 31,000 | 95 | ||||||
| 6082 | 8 | 295 | 95 | – | 240 | – | – | |||||
| 7075 T6, T651 | 11 | 83-572 | 73- 503 | 150 | ||||||||
| 7075 T73, T7351 | 13 | 73-503 | 63-434 | NA | ||||||||
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Choosing Aluminium Coil Tubing from Liam Pipes and Tubes ensures high-quality, reliable performance for various industrial applications. As a trusted manufacturer and supplier in Houston , USA, Liam Pipes and Tubes offers precision-engineered aluminium coil tubing known for its exceptional strength, corrosion resistance, and lightweight properties. The company adheres to strict quality standards, providing durable, long-lasting products that meet industry specifications. With a commitment to customer satisfaction, prompt delivery, and technical support, Liam Pipes and Tubes is the ideal choice for your aluminium coil tubing needs.
Liam Pipes and Tubes, one of the largest suppliers of Aluminium Coil Tubing in Houston , USA, offers a comprehensive range of high-quality pipes and tubes suitable for various industrial applications. Their extensive inventory and commitment to exceptional service make them a go-to choice for stainless steel products in the region.
Yes, we offer custom sizes for Aluminium Coil Tubing to meet your specific requirements. Our team at Liam Pipes and Tubes is committed to providing tailored solutions for all your Piping & tubing needs. For more details, contact us at sales@liampipes.us.
| Grade | UNS | USA | Japan | France | ISO | WNR | EN | DIN | ISO | BS (OLD) |
| 1100 | A91100 | AA1100 | JIS A1100P | NF 1100 | Al 99.0 Cu. | – | – | – | – | – |
| 6082 | A96082 | AA6082 | – | – | – | 3.2315 | AW-6082 | AlMgSi1 | AlSi1MgMn | HE30 |
| 5083 | A95083 | 5083 | – | – | AlMg4,5Mn0,7 | 3.3547 | AW-AlMg4,5Mn0,7 | AlMg4,5Mn | – | – |
| 6061 | A96061 | AA6061 | – | – | – | 3.3211 | AW-AlMg1SiCu EN AW-6061 | AlMgSiCu | AlMg1SiCu | HE20 |
| 7075 | A97075 | 7075 | 3.4365 | ENAW-AlZn5.5MgCu EN AW-7075 | AlZnMgCu1.5 | AlZn6MgCu | 7075 L95 L96, V95 |
Aluminium Coil Tubing is used extensively in applications that require light, flexible, and corrosion-resistant materials. In HVAC applications, it provides smooth air and_also heat transfer in air conditioners and refrigerators. This is also widely utilized in automotive applications such as fuel lines, brake systems, and coolant routing to aid in weight savings and energy savings. In medical devices, it is used due to its non-corrosive and hygienic characteristics to transport fluids. Moreover, aluminum coil tubing is used in plumbing, aerospace, and electronics and provides consistent performance where space efficiency, cleanliness, and durability are essential.
