Liam Pipes and Tubes is a trusted manufacturer and supplier of Inconel 617 pipes, based in Houston, USA. With a strong emphasis on quality and performance, this company delivers top-notch alloy piping solutions designed for high-temperature and high-stress industrial settings. The Inconel 617 pipes from Liam Pipes and Tubes are specifically engineered to thrive in tough environments, such as chemical plants, aerospace systems, and power generation facilities. Thanks to their customer-first approach, competitive pricing, and commitment to international standards, Liam Pipes and Tubes has built a solid reputation as a reliable source for Inconel 617 pipes, both domestically and globally.
Inconel 617 pipes are primarily made up of nickel (about 44.5–62%), along with chromium (20–24%), cobalt (10–15%), molybdenum (8–10%), and trace amounts of aluminum and carbon. These components give the alloy its remarkable resistance to oxidation and carburization at elevated temperatures. On the mechanical side, Inconel 617 boasts a tensile strength of around 760 MPa, a yield strength of 350 MPa, and an elongation of about 30%. It maintains its structural integrity and creep resistance even at temperatures exceeding 1000°C. Plus, the alloy is weldable and has good formability, making it a great choice for various complex industrial applications.
Specifications ASTM B167, B546 / ASME SB167, SB546,
Dimensions ASTM, ASME and API
Size Range 15″NB – 150″NB
Outer Diameter 6.35 mm OD upto 254 mm OD in 0.6 TO 20 mm thickness.
Schedule SCH 10, SCH20, SCH30, SCH40, STD, SCH60, XS, SCH80, SCH120, SCH140, SCH160, XXS
Type Seamless / ERW / Welded / Fabricated / LSAW Pipes
Length Single Random, Double Random & Cut Length
Form Round Pipes/Tubes, Square Pipes/Tubes, Rectangular Pipe/Tubes, Coiled Tubes, “U” Shape, Pan Cake Coils, Hydraulic Tube
Grade 617 UNS (N06617), DIN (2.4663)
| C | Mn | S | Si | Cr | Mo | Ni | Cu | Ti | Al | B | Co | Fe |
| 0.05-0.15 | 1.0 Max | 0.015 Max | 1.0 Max | 20.0-24.0 | 8.0-10.0 | 44.5 Min | 0.5 Max | 0.6 Max | 0.8-1.5 | 0.006 Max | 10.0-15.0 | 3.0 Max |
| Density | Melting Point | Tensile Strength | Yield Strength (0.2%Offset) | Elongation |
| 8.1 g/cm3 | 1411 °C (2571 °F) | Psi – 80,000 , MPa – 550 | Psi – 30,000 , MPa – 205 | 30 % |
We provide products that come with both mill test certificates and third-party test certificates, ensuring the highest standards of quality and compliance.
Inconel 617 pipes find extensive use in settings that require exceptional high-temperature strength and corrosion resistance. They are perfect for heat exchangers, reformer tubes, gas turbines, petrochemical processing equipment, and combustion chambers. In the power generation sector, particularly in advanced gas-cooled reactors and high-efficiency fossil fuel plants, these pipes consistently perform well under prolonged thermal exposure. The alloy’s resistance to oxidation, nitriding, and sulfidation further enhances its reliability in demanding applications.
Liam Pipes and Tubes, a top supplier of Inconel 617 Pipes in Houston , USA, offers a comprehensive range of high-quality pipes and tubes for various industrial applications. With an extensive inventory and a commitment to exceptional customer service, they have become the go-to source for stainless steel products in the area.
At Liam Pipes and Tubes, we specialize in providing custom-sized Inconel 617 Pipes designed to meet your specific requirements. Our expert team is committed to delivering personalized solutions for all your piping and tubing needs. For more details, contact us at sales@liampipes.us.
Inconel 617 pipes are widely used in high-temperature and corrosive environments across various industries. Their primary applications include aerospace components, such as gas turbine engines and combustion chambers, where thermal stability and strength are crucial. In the power generation sector, these pipes are utilized in heat exchangers, nuclear reactors, and gas turbines. They are also essential in chemical processing, particularly in environments involving high-pressure and high-temperature conditions. Additionally, Inconel 617 pipes are employed in petrochemical applications, ensuring reliable performance and longevity in demanding conditions.
